Stainless Steel · 316 · Compact Pedestrian

SmartMover SM100+ SS

Compact 316 stainless pedestrian tug — 1,200 kg on castors, cleanroom-ready.

Key specifications

Load capacity: 1,200 kg (4,800 kg on rails)
IP rating: IP44
Runtime: 7.7 km / charge
Charge time: 4h 30m (AGM) · 1h 45m (Li)

Request a Quote Download Brochure (01) 401 9919

Official MasterMover Distributor

Factory-trained Engineers

Nationwide Support

Key benefits

Why operations choose the SmartMover SM100+ SS

High Capacity

Moves loads up to 1,200 kg (4,800 kg on rails).

No Operator Licence

Pedestrian-operated — no forklift licence required.

Compact & Manoeuvrable

Fits standard aisles, doorways and lifts where forklifts can't go.

Battery Powered

Quiet, zero-emission electric drive. Easy to operate.

About this model

SmartMover SM100+ SS — overview

The SM100+ SS delivers the full performance of MasterMover's compact pedestrian range in high-grade 316 stainless steel with a 180-grit satin finish — engineered to integrate seamlessly into biopharmaceutical cleanrooms, medical device production and hygienic food environments. A hydraulic coupling generates 387 kg of clamp force at the load for an unbreakable connection, while twin electric motors and interchangeable batteries deliver push/pull loads up to 1,200 kg on castors (4,800 kg on rails) on slopes to 30°. Automatic regenerative braking, anti-crush button, warning horn and battery discharge indicator are standard.

Key features

316 stainless steel · 180-grit satin (0.76 μ)
IP44 rated for hygienic environments
Twin electric motor · regenerative braking
Hydraulic coupling — 387 kg clamp force
Interchangeable AGM or Lithium battery
Anti-crush · warning horn · automatic parking brake

Applications

Where the SmartMover SM100+ SS fits

Pharma & biopharma cleanrooms

Medical device & sterile

Food & beverage production

Washdown & GMP zones

Technical data sheet

Download the SmartMover SM100+ SS brochure

Download Brochure (PDF)

Technical data

Full specifications

Maximum load (castors): 1,200 kg
Maximum load (rails): 4,800 kg
Max push / pull force: 1,079 N / 1,079 N
Machine weight: 72 kg
Drive: Twin electric motor · 2 × 0.22 kW
Voltage: 24 V
Standard speed: 4.2 km/h (5.4 hare / 1.8 tortoise optional)
Maximum slope: 30°
Metalwork finish: 316 stainless · 180-grit to 0.76 μ satin
IP rating: IP44
Battery (AGM): 24 V · 22 Ah · 7.7 km / 4h 30m charge
Battery (Lithium optional): 24 V · 39 Ah · 15.5 km / 1h 45m charge
Coupling: A-Frame (straight / angled), Box Section, Variable Kit

Download the full Stainless Steel · 316 · Compact Pedestrian brochure

Enquire about the SmartMover SM100+ SS

Speak to a MasterMover specialist

Tell us about the loads you need to move — weight, wheels, environment — and we'll recommend the right unit, with a free on-site demo, transparent pricing and finance options.
