CDDR · AC Walkie Stacker (CDDR15-I / -II)
Xilin CDDR15
1.5 t AC walkie stacker — full-free lifting mast, lift heights to 5,600 mm.
Key specifications
- Capacity
- 1,500 kg
- Power
- 24 V AC electric
- Max lift height
- 2,500–5,600 mm
- Turning radius
- 1,575 mm
Authorised Xilin dealer
Factory-trained engineers
Nationwide delivery
About this model
Xilin CDDR15 — overview
The Xilin CDDR15 is a 1.5 tonne walkie stacker (CDDR15-I / -II variants) with AC CANbus control and regenerative braking. Full-free lifting mast lets a 3 m truck pass through a 2 m door; lift heights extend to 5,600 mm.
Key features
- AC control with CANbus + regenerative braking
- Full-free lifting mast (1,300–1,940 mm FFL)
- Lift heights 2,500–5,600 mm
- Optional Li-ion battery (24 V / 150 or 230 Ah)
Technical data sheet
Download the Xilin CDDR15 brochure
Technical data
Full specifications
- Model
- CDDR15-I / CDDR15-II
- Load capacity
- 1,500 kg
- Drive motor
- 1.5 kW AC (-I) / 1.2 kW AC (-II)
- Battery
- 24 V / 240–300 Ah (Li-ion option)
- Travel speed (laden / unladen)
- 5.8 / 6.0 km/h
- Free lift
- 1,300–1,940 mm
Enquire about the Xilin CDDR15
Speak to a Xilin-trained specialist
Tell us about your operation — capacity, environment, shift pattern — and we'll recommend the right unit, with transparent pricing, lead time and finance options.
- · Free site visit and operational assessment
- · Flexible finance, contract hire and lease options
- · Trade-in of your existing fleet considered
- · Nationwide delivery, factory-trained engineers
